Pinch Dynamometer

The unique electronic Pinch Dynamometer (Pinchmeter) has a low-profile design that enables the researcher to accurately quantify pinch strength at closer to end range than any other device.

Designed to work in compression with a rated load between 0 to 22.5kg (50lb). The Pinchmeter (P200) is able to connect with any of the Biometrics Ltd wireless and wired interfaces, or other 3rd party instrumentation.

Specifications

Dimensions Diameter 45 x 6mm Mass 65g
Accuracy Better than 0.6% Rated Load Rated Load 0 to 22.5Kg, or 0 to 50lb
Wireless Connection DataLITE Adaptor

DataLITE Adaptor

Adaptor Details

Dimensions 67 x 29 x 15 mm
Mass 34g
Enclosure Material Acetal CoPolymer
Sampling Rate User selectable of 2000, 1000, 500 or 200 samples per second
Bandwidth DC to 1kHz, +0dB/-3dB (reduced by sampling rates lower than 2000)
Battery Lithium Polymer rechargeable
Battery Life Fully charged battery life in excess of 15 hours with the Pinchmeter
Wireless Connection A DataLITE Adaptor is needed to pair a Pinchmeter with a DataLITE interface
Wireless Range Up to 30m
Wireless Transmission Data Loss Tolerant for 100 mS
Wired Connection Cable lengths available: 500mm, 1000mm, 1500mm
(custom lengths available on request)
Wireless Interface DataLITE PIONEER, ADVANCE, EXPLORE Wired Interface DataLOG, DataLINK, Amplifier or 3rd party

Biometrics Hand Held Dynamometer is used extensively in the fields of ergonomics, sports science and medical research where measurements are commonly taken for a wide range of applications such as:

  • Grip Strength and Fatigue
  • Manual Muscle Testing
  • Bilateral Strength Testing
  • & Many More!
