Exercise Kit

The E-LINK Exercise Kit consists of Myo-EX and AngleX sensors that are exclusively designed for innovative computer-based exercise.

Myo-EX and AngleX are used in a wide variety of clinical settings, from hand therapy to stroke and neuro rehabilitation.


Highly sensitive Myo-EX sensors use surface EMG for inspiring exercise, beginning from when there is the tiniest flicker of voluntary muscle activity, with or without visible joint movement.

The same sensors can be used throughout the full spectrum of muscular activity and rehabilitation, even to that of the professional athlete.

As soon as there is the smallest flicker of voluntary muscle control returning, ingenious Myo-EX sensors use surface EMG to detect the tiniest electrical activity, enabling exercise to begin even when there is very little or no visible joint movement.

Myo-EX is extremely useful for tendon transfers and radial nerve injuries in hand therapy or for patients in the acute phase of stroke recovery.

Mini Case History #1 - Using the Myo-EX

The new wireless Myo-EX sensor is simply and speedily placed over the muscle to be exercised and data is immediately transmitted directly to the computer via the wireless Dongle. As the patient is no longer tethered to an interface unit the wireless Myo-EX provides full freedom of movement for exercise, even at some distance from the work station, especially if a large monitor is used. This is particularly beneficial for shoulder and lower limb exercise.

Mini Case History #2 - Using the Myo-EX

The immediate visual feedback from the moving objects in the Activity helps the patient know when they are actually activating the muscle. Normal movement patterns are subsequently encouraged as the patient focuses on smooth, efficient and co-ordinated motor control in order to succeed in the activity. As the patient's attention is drawn to a normal movement pattern, unnecessary compensatory movements are thereby discouraged.

  • Easy and quick to use in busy clinical environments
  • Sensors are applied to clean, dry skin over the muscle area to be exercised
  • The Wireless Myo-EX sensor is applied to the skin with die-cut medical grade hypoallergenic tape
  • The precision sensor is designed to give superb quality of signal and can detect as little as 3-4 microvolts of electrical activity
  • The full scale reaches 3000 microvolts which may be seen in larger deltoid, bicep or quad muscles
  • Minimum and maximum readings are quickly assessed and used as the parameters for the E-LINK Activities
  • Biofeedback is immediate to the patient through the movement of objects on the screen providing a high degree of motivational exercise
  • Myo-EX is ideal for wrist extension exercise, focused exercise on the shoulder musculature, knee exercise and has been used by Speech and Language Therapists for certain facial muscles


Where there is active joint movement, AngleX sensors encourage focused exercise against gravity for small DIP joints through to the larger joints of the upper and lower extremities.

Where there is some joint movement but not yet sufficient to grasp or move other devices, AngleX is the ideal tool to use. The new innovative wireless AngleX sensors are easily attached to the skin, close to the joint to be exercised and communicate data direct to the Computer via the Dongle.

Mini Case History #3 - Using the Hand Kit and AngleX

AngleX is very beneficial for a variety of clinical areas needing a tool for focused exercise - from hand therapy clinics to Stoke, Neuro and Spinal Injury Units. AngleX sensors are also perfect to use with patients of all ages.

Mini Case History #4 - Using the Hand Kit and AngleX

  • Easy and quick to apply in busy clinical environments
  • Using medical grade hypoallergenic tape, sensors are applied to clean, dry skin, close to the joint to be exercised
  • The small AngleX is used for the fingers, thumb and wrist
  • The large AngleX is used for the forearm, elbow, shoulder, back, neck, hip, knee and ankle joints
  • Baseline readings are taken in 1 degree increments for the active ranges of motion. These are automatically entered as the parameters for the chosen Activity which can be graded to suit therapy goals
  • Biofeedback is immediate to the patient through the movement of objects on the screen, providing a high degree of motivation for exercise
  • AngleX encourages and reinforces normal movement patterns

Exercise Activities

Combined with the Myo-EX or AngleX, E-LINK Activities provide gradable exercise for all age groups throughout the full rehabilitation process, encouraging muscle strengthening and restoration of normal movement patterns.

The Activities incorporate a fun element into the therapy session, maximizing the patient's motivation and tolerance to exercise.

  • Using the Myo-EX or AngleX, baseline measurements are quickly taken and these are automatically entered as the range for the chosen Activity so that the patient can exercise to his/her individual capability
  • All the Activities can be graded to suit patient need or therapy goals
  • Various Activities with eye-catching graphics are designed as the visual feedback for the patient to engage in gross motor control through to finer controlled movement
  • Biofeedback is immediate to the patient through the movement of objects on the screen
  • The various Activities are designed for working randomly throughout the set range (for example, catching balls in a moving bucket) or to the limits of the set range (for example, moving containers from a dockside onto a ship). Some Activities also address cognitive and perceptual issues (for example, matching colors or shapes)
  • A percentage score and an Activity distribution graph are generated at the end of play for further objective analysis and re-assessment of therapy goals
  • All measurements and exercise results are displayed in table and graph format and form part of the patient's record
  • Activities can be saved after each play and the Sequence of Activities used immediately at the next session, saving set up time for the Therapist and familiarising the patient to the Activity

Wireless M800

  • Myo-EX (GX5)
  • Large & Small AngleX (NC5 & NC6)

Wired M600

  • Myo-EX (GX3 & GX4)
  • Large & Small AngleX (NC3 & NC4)

The M800 Myo-EX and AngleX sensors communicate wirelessly with the E-LINK software via the wireless Dongle (DG1) attached to the USB port of the computer.

The M600 Wired Exercise Kit requires the wired X4 Interface Unit as the interface to the computer

Minimum Computer Specifications
